Crohn’s disease: failure of a proprietary fluorescent in situ hybridization assay to detect M. avium subspecies paratuberculosis in archived frozen intestine from patients with Crohn’s disease.

Abstract

Objectives

Although controversial, there is increasing concern that Crohn’s disease may be a zoonotic infectious disease consequent to a mycobacterial infection. The most plausible candidate is M. avium subspecies paratuberculosis (MAP) that is unequivocally responsible for Johne’s disease in ruminants. The purpose of this study was to evaluate a proprietary (Affymetrix™ RNA view®) fluorescent in situ hybridization (FISH) assay for MAP RNA. Non-identifiable intestine from patients with documented Crohn’s disease was assayed according to the manufacturer’s instructions and with suggested modifications. Probes were custom designed for MAP and human β-actin (as the eukaryotic housekeeping gene) from published genomes.

Results

Repetitively, false positive signal was observed in our “No-Probe” negative control. Attempts were made to correct this according to the manufacturer’s suggestions (by modifying wash solutions, using recommended hydrochloric acid titration and different fluorescent filters). None prevented false positive signal in the “No-Probe” control. It is concluded that when performed according to manufactures instruction and with multiple variations on the manufactures recommended suggestions to correct for false positive signal, that the Affymetrix™ RNA view® cannot be used to detect MAP in pre-frozen resected intestine of humans with Crohn’s disease.

Introduction

Johne’s disease [1] a chronic wasting intestinal infection in animals is caused by M. avium subspecies paratuberculosis (MAP). Viable MAP is found in the human food chain including pasteurized milk in the US [2] and Europe and chlorinated municipal water [3]. There is increasing concern that MAP may be zoonotic. [4] and might be an etiological trigger for Crohn’s disease, an affliction evocative of Johne’s disease [3, 5,6,7] The gold standard of diagnosis of Johne’s disease is culture of MAP [8]. In animals with Johne’s disease, this is a reliable, but time-consuming process. Multiple other diagnostic modalities exist for detecting mycobacteria in general [8,9,10,11] and MAP in particular. [12,13,14,15,16] Following the detection of putative MAP, confirmation usually requires the identification of the DNA sequence IS900 which is unique to MAP [17].

In humans with Crohn’s disease, Ziehl [18]-Neelsen [19] staining, usually visualized at × 400 magnification, does not identify mycobacteria [6, 7]. Using oil-immersion microscopy (×1000 magnification) M. avium was identified in Crohn’s disease. [20] Although MAP has been cultured from humans with Crohn’s disease [21], this is difficult, few laboratories can do so [22,23,24,25,26], and up to 18 months may be required for the organism to reconstitute its cell wall [21]. The detection of MAP DNA does not signify that the organism was viable [27]. In contrast, detecting MAP RNA implies viability [3]. It would therefore be of use to develop an assay that reliably and rapidly identifies MAP RNA in possibly infected intestine.

We herein report on our attempts to develop a fluorescent in situ hybridization (FISH) assay of MAP RNA, using two proprietary RNA amplification techniques. One is specifically designed for tissue (Affymetrix™ RNA view®. View ISH Tissue Assay Kit 96 2-Plex. Thermo Fisher Catalog Number: QVT0013.) The second is a product specifically designed for isolated cell assays (ViewRNA ISH Cell Assay Kit; Invitrogen by Thermo Fisher Scientific: Catalog Number: QVC0001.) In this report we studied multiple tissues. Initially, intestine from patients with Crohn’s disease that had been snap frozen in liquid nitrogen and stored at − 80 ℃ until processed for assay. Human intestine studied included frozen sections, routinely imbedded paraffin tissue and autopsy specimens. As further controls, intestine from ruminants with Johne’s disease were evaluated. Finally, we evaluated human buffy coat circulating white blood cells (WBC’s.)

Main text

This study was approved by the Research & Development Committee at the VAMC Bronx NY (0720-06-038.) The methods and results with bovine ileal intestinal tissue, with and without Johne’s disease have been published [28]. The non-identifiable tissue from individuals with and without Crohn’s disease were archived samples that had been stored at − 80 ℃.

The tissue and assay were handled in an identical manner to that of the published bovine study [28], with one exception. Previously, at our request Affymetrix had generated probes that were species specific from published gene sequences. In this study the housekeeping gene was Human Specific β-actin (Affymetrix Catalog # VA6-10506-1 Probe type 6) As in the previous study for MAP, an Affymetrix generated probe designed using the published sequence [17]. (Affymetrix name: M. tuberculosis Is900: Cat # VF1 19496: Lot # 195634523: Probe type 1.) Previously, the house keeping gene for ruminants was bovine β-actin (Bos Taurus actb: NCBI Reference Sequence: NM_173979.3 (Affymetrix name: Bos Taurus Actb: Cat# VF6 20062: Lot # 200642784: Probe Type 6.) We also use 16S Bacterial, Probe type 6, Cat # VF-6-16576-01: 16 S E. coli, Probe type 1 Cat # VF1-19200-01: 16S Mycobacterium tuberculosis Probe type 1, Cat # VF1-16224-01: Human β-Actin (ACTB Human) Probe type 1, Cat # VA1-10351-01: Bovine β-Actin (ACTB BOB TAURUS)Probe type 1 Cat# VF1-20959-01: IS 900 (M. avium subspecies paratuberculosis) Probe type 6, Cat # VF6-20958-01: IS6110 (Mycobacterium tuberculosis) Probe type 1, Cat # VF1-6000090-01: and Human GAPD (glycaraldehyde-3-phosphate dehydrogenase) (As an additional house-keeping gene) Probe type 6 Cat # VA6-100337-01. All these probes are proprietary to Affymetrix.

All human tissues were non-identifiable. Different from our previous study [28], on human samples the house keeping genes were human specific β-actin probe and human GAPD (glycaraldehyde-3-phosphate dehydrogenase). Initial human intestinal studies were carried out identically as published [28]. Repetitively a clear background could not be observed in the control slide, from which probes had been excluded during the Probe Set Hybridization steps (Fig. 1). The Affymetrix ViewRNA™ ISH Tissue 2-Plex Assay instructions, suggests pretreating tissue with HCl to prevent false positive signal (Affymetrix: Protocol Guide for RNA in situ Hybridization. Troubleshooting for high background. Page 71.) As previously, multiple attempts were made to obtain a clear background. Figure 1 shows “positive signal With-Probe with an HCL wash. However, Fig. 2 likewise shows “positive” signal when No-Probes are used. Figure 3 shows “positive” signal when No-Probes are used with a 15 min 0.2 M HCl wash.

Fig. 1
figure1

From a sample of intestine from a patient with Crohn’s disease. a DAPI; b Texas Red (IS900 an insertion sequence unique to M. avium subspecies paratuberculosis.); c Cy-5 (Human β-actin; a housekeeping control gene) d composite of ac. Note “positive” signal in the “with-probe” in Fig. 1 panels bd. Marker bars in µm indicates magnification of × 40

Fig. 2
figure2

No-Probe Control for Fig. 1. A composite of four images of the same section, of human Crohn’s disease intestine. Processed identically as in Fig. 1, during the same experiment, but NO-probes were added during the hybridization step. a DAPI; b Texas Red; c Cy-5 (d composite of ac.) Note “positive” signal in Fig. 1bd. Marker bars in µm indicates magnification of × 40

Fig. 3
figure3

“No-probe” negative for a 15-min exposure to 0.2 M HCl. a DAPI; b Texas Red; c Cy-5 (d composite of ac.) Note the “positive” signal in this “No-probe” control for Fig. 3bd. Marker bars in µm indicates magnification of × 40. (See Additional file 1 for the With-Probe control for this Figure.) The incubation with HCl is recommended to correct for false positive due to endogenous alkaline phosphatase in the tissue being studied

Multiple additional experiments were performed in an attempt to obtain truly negative No-Probe controls. We have previously presented some of our data concerning both time and concentration titration of exposure to HCl. Additional file 1, (the With Probe Control for Fig. 3) shows the results of treating with 0.2 M HCl for 15 min. Next, we attempted to see whether we could study human intestinal autopsy samples. Because we were using archived frozen samples, we attempted to study other human intestinal. Additional file 2 shows a comparison of routine surgical resected intestine (Panel A) with autopsy colon (Panel B, obtained approximately 24 h following death.) The profound autolysis precludes autopsy tissue being used. We then studied archived paraffin imbedded samples of human intestine. Additional file 3 shows de-paraffinized human tissue probed with 16S E. Coli and human β-actin. The positive signal noted is also seen in the No-Probe control (Additional file 4. See Panel “C”.) We concluded that paraffinized tissue cannot be used in this assay. We next examine tissue sent for frozen section. Additional file 5 was probed with 16S bacterial probe and human β-actin. The No-Probe control (Additional file 6) has abundant false positive signal (see white square marker Panel “C”. We conclude that fresh tissue taken from frozen sections also exhibit false positivity. Frozen bovine tissue was then probed (Additional file 7) with Bovine β-actin and IS900. The No-Probe control for exhibits abundant false positive signal (Additional file 8 Panels “B”, “C” & “D”.) We conclude that the false positive signal previously shown [28] is reproducible.

False positive signal may be due to endogenous alkaline phosphatase activity. This can be identified by staining with Fast Blue Substrate (Additional file 9). Affymetrix Technical support states that this may be corrected by incubating in 0.2MHCl for 15 min [28]. We present previously unpublished data of our titrations at 25 min with probes (Additional file 10) and without probes (Additional file 11), and increased HCL concentration (0.4 M) with probes (Additional file 12). The No-Probe Control is Additional file 13. We conclude that HCl treatment did not correct false positive signal.

Because circulating white blood cells (WBC’s) may harbor mycobacteria, we next studied WBC’s obtained from buffy coat obtained using a Ficoll gradient. Additional file 14 is with and Additional file 15 is without probes. Although the false positive signal is less pronounced in isolated WBC’s it is still present. We attempted to use RNA Paxgene®, but full hemolysis occurred, so no WBC’s could be obtained. As an alternative, we evaluated DNA Paxgene® to draw blood. Additional file 16 is with probes and Additional file 17 is its No-Probe control. Both DNA Paxgene ® tubes give poor quality images. As the No-Probe controls showing false positive signal, we conclude that DNA Paxgene ® has no role in establishing a WBC FISH assay.

We next studied two house-keeping genes human β-actin and human GAPD (glycaraldehyde-3-phosphate dehydrogenase.) For this we used a different kit specifically designed for singles cells (ViewRNA ISH Cell Assay Kit ®.) Clean positive signal with both probes is seen in Additional file 18. They are always colocalized to DAPI positive regions; indicating that the signal is associated with white blood cells. In contrast, False positive signal is only seen in the No-Probe control (Additional file 19). Specifically, the Cy-5 field shows no background whatsoever. Uniquely in these studies, but only with the single Cell Assay Kit, we consider that this ViewRNA ISH Cell Assay Kit ®, on WBC’s may represent genuine signal.

We then evaluated the utility of RNALater® on WBC’s. Blood was stored at 4 ℃ for 24 h prior to isolating the buffy coat. Additional file 20 present the with probe and Additional file 21 its No-Probe control. False positive signal is present the No-Probe control.

Because of the encouraging data from Additional files 18 and 19, we then evaluated the Single cell Affymetrix assay on bovine Johne intestine both with (Additional file 22) and without (Additional file 23) probes. Because of abundant positive signal in the No-Probe control (Additional file 23 panels “B”, “C” and “D”) we conclude that the Single cell Affymetrix system ViewRNA ISH Cell Assay Kit ® CANNOT be used to study intestinal tissue in lieu of Affymetrix™ RNA view® Tissue assay kit ®.

During our efforts to obviate false positive signal we repetitively contacted the Technical staff at ThermoFisher Affymetrix. They provided us with a Rat Kidney Control Kit that contained three slides. Two had reciprocal probe sets (types 1 and 6.) The third slide was ThermoFisher’s “No-Probe” control. In Additional file 24 we show the Affymetrix provided No-Probe control with false positive signal (See panels’ B”, “C” and “D.”)

We have previously shown that this false positive “No-probe” signal cannot be ascribed to contamination of the negative control slide by probes during the post hybridization wash or obtained by increasing the stringency or duration of the HCL pretreatment, nor did using different filters (TritC for Texas-Red, and for Cy-5 a custom recommended filter set “Hope” [28] recommended by the technical staff at Affymetrix prevent false positive signal.

A proprietary FISH assay has been performed according to the recommended conditions of the vendor. Purportedly positive signal was detected for both MAP (IS900) and our eukaryotic housekeeping gene, human β-actin. However, repetitively the “No-Probe” negative control for a given experiment showed obviously false “positive” signal.

It is concluded that when the assay is performed according to the Affymetrix ViewRNA™ ISH Tissue 2-Plex Assay recommended instructions, it cannot be used for FISH studies to identify the RNA of MAP on previously frozen Crohn’s disease intestine.

There were compelling reasons to initiate these studies. MAP is known to cause Johne disease. It MAY be causative in both Crohn disease and multiple sclerosis. These concerns are addressed in the introduction to our three manuscripts. We stand by our conclusions that QVT0013 cannot be used to determine the presence or absence of MAP in the three diseases studied under the conditions under which they were studied. We concluded that by publishing our findings others in the scientific community would waste neither the time, energy nor expense in performing identical studies

Limitations

In this study we asked a binary question. Is MAP present or absent in a given sample of intestine obtained from humans with Crohn’s disease? Especially when the target is expected to be in low abundance, any background may result in a false positive interpretation and is unacceptable. In contrast, when a change in gene expression is being quantified for example comparing normal with inflamed tissue, a low FISH signal to noise background may be acceptable. Accordingly, our conclusions apply only to frozen intestinal tissue where we are attempting to identify presumably low abundance MAP and not to other scientific investigations.

The ViewRNA™ ISH Tissue 2-Plex Assay is designed to study tissue, not isolated cells. Encouragingly, when circulating WBC’s are studied using the ViewRNA ISH Cell Assay Kit®, possibly reliable data have been obtained. However, this ViewRNA ISH Cell Assay Kit cannot be used on tissue; only WBC’s. Although the ThermoFisher provided No-Probe slides had positive signal, it was not stated whether these had been frozen prior to processing. Our studies were not performed on fresh tissue. Therefore, our conclusions should only be applied to frozen, not fresh, intestine.

Availability of data and materials

Data presented in manuscript.

Abbreviations

MAP:

M. avium subspecies paratuberculosis

FISH:

Fluorescent in situ hybridization

HCL:

Hydrochloric acid

References

  1. 1.

    Johne HA, Frothingham L. Ein eigenthumlicher fall von tuberculose beim rind (a particular case of tuberculosis in a cow). Dtsch Zeitschr Tiermed, Vergl Pathol. 1895;21:438–54.

    Google Scholar

  2. 2.

    Ellingson JL, Anderson JL, Koziczkowski JJ, Radcliff RP, Sloan SJ, Allen SE, Sullivan NM. Detection of viable Mycobacterium avium subsp. paratuberculosis in retail pasteurized whole milk by two culture methods and PCR. J Food Prot. 2005;68(5):966–72.

    CAS  Article  Google Scholar

  3. 3.

    Mishina D, Katsel P, Brown ST, Gilberts EC, Greenstein RJ. On the etiology of Crohn disease. Proc Natl Acad Sci USA. 1996;93(18):9816–20.

    CAS  Article  Google Scholar

  4. 4.

    Schurr E, Gros P. A common genetic fingerprint in leprosy and Crohn’s disease? N Engl J Med. 2009;361(27):2666–8.

    CAS  Article  Google Scholar

  5. 5.

    Greenstein RJ, Collins MT. Emerging pathogens: is Mycobacterium avium subspecies paratuberculosis zoonotic? Lancet. 2004;364(9432):396–7.

    Article  Google Scholar

  6. 6.

    Dalziel TK. Chronic intestinal enteritis. BMJ. 1913;ii:1068–70.

    Google Scholar

  7. 7.

    Crohn BB, Ginzberg L, Oppenheimer GD. Regional Ileitis. J Amer Med Assoc. 1932;99:1323–8.

    Article  Google Scholar

  8. 8.

    Ricchi M, Bertasio C, Boniotti MB, Vicari N, Russo S, Tilola M, Bellotti MA, Bertasi B. Comparison among the quantification of bacterial pathogens by qPCR, dPCR, and cultural methods. Front Microbiol. 2017;8:1174.

    Article  Google Scholar

  9. 9.

    Rodriguez D, Daniels AU, Urrusti JL, Wirz D, Braissant O. Evaluation of a low-cost calorimetric approach for rapid detection of tuberculosis and other mycobacteria in culture. J Appl Microbiol. 2011;111(4):1016–24.

    CAS  Article  Google Scholar

  10. 10.

    Stewart LD, McNair J, McCallan L, Gordon A, Grant IR. Improved detection of Mycobacterium bovis infection in bovine lymph node tissue using immunomagnetic separation (IMS)-based methods. PLoS ONE. 2013;8(3):e58374.

    CAS  Article  Google Scholar

  11. 11.

    Shah J, Weltman H, Narciso P, Murphy C, Poruri A, Baliga S, Sharon L, York M, Cunningham G, Miller S, et al. Dual color fluorescence in situ hybridization (FISH) assays for detecting Mycobacterium tuberculosis and Mycobacterium avium complexes and related pathogens in cultures. PLoS ONE. 2017;12(4):e0174989.

    Article  Google Scholar

  12. 12.

    Keown DA, Collings DA, Keenan JI. Uptake and persistence of Mycobacterium avium subsp. paratuberculosis in human monocytes. Infect Immun. 2012;80(11):3768–75.

    CAS  Article  Google Scholar

  13. 13.

    Stewart LD, Foddai A, Elliott CT, Grant IR. Development of a novel phage-mediated immunoassay for the rapid detection of viable Mycobacterium avium subsp. paratuberculosis. J Appl Microbiol. 2013;115(3):808–17.

    CAS  Article  Google Scholar

  14. 14.

    Husakova M, Dziedzinska R, Slana I. Magnetic separation methods for the detection of Mycobacterium avium subsp. paratuberculosis in various types of matrices: a review. Biomed Res Int. 2017;2017:5869854.

    Article  Google Scholar

  15. 15.

    Foddai A, Elliott CT, Grant IR. Optimization of a phage amplification assay to permit accurate enumeration of viable Mycobacterium avium subsp. paratuberculosis cells. Appl Environ Microbiol. 2009;75(12):3896–902.

    CAS  Article  Google Scholar

  16. 16.

    Imirzalioglu C, Dahmen H, Hain T, Billion A, Kuenne C, Chakraborty T, Domann E. Highly specific and quick detection of Mycobacterium avium subsp. paratuberculosis in Feces and gut tissue of cattle and humans by multiple real-time PCR assays. J Clin Microbiol. 2011;49(5):1843–52.

    CAS  Article  Google Scholar

  17. 17.

    Green EP, Tizard ML, Moss MT, Thompson J, Winterbourne DJ, McFadden JJ, Hermon-Taylor J. Sequence and characteristics of IS900, an insertion element identified in a human Crohn’s disease isolate of Mycobacterium paratuberculosis. Nucleic Acids Res. 1989;17(22):9063–73.

    CAS  Article  Google Scholar

  18. 18.

    Ziehl F. Zur Farbung des Tuberkelbacillus. Dtsch, med Wschr. 1882;8:451.

    Article  Google Scholar

  19. 19.

    Neelsen FCA. Ein casuistischer Bietrag zur Lehre von der Tuberkulose. Zbl med Wiss. 1883;21:497–501.

    Google Scholar

  20. 20.

    Jeyanathan M, Boutros-Tadros O, Radhi J, Semret M, Bitton A, Behr MA. Visualization of Mycobacterium avium in Crohn’s tissue by oil-immersion microscopy. Microbes Infect. 2007;9(14–15):1567–73.

    CAS  Article  Google Scholar

  21. 21.

    Chiodini RJ, Van Kruiningen HJ, Merkal RS, Thayer WR Jr, Coutu JA. Characteristics of an unclassified Mycobacterium species isolated from patients with Crohn’s disease. J Clin Microbiol. 1984;20(5):966–71.

    CAS  Article  Google Scholar

  22. 22.

    Gitnick G, Collins J, Beaman B, Brooks D, Arthur M, Imaeda T, Palieschesky M. Preliminary report on isolation of mycobacteria from patients with Crohn’s disease. Dig Dis Sci. 1989;34(6):925–32.

    CAS  Article  Google Scholar

  23. 23.

    Chiodini RJ, Van Kruiningen HJ, Thayer WR, Coutu JA. Spheroplastic phase of mycobacteria isolated from patients with Crohn’s disease. J Clin Microbiol. 1986;24:357–63.

    CAS  Article  Google Scholar

  24. 24.

    Coloe P, Wilkes CR, Lightfoot D, Tosolini FA. Isolation of Mycobacterium paratuberculosis in Crohn’s disease. Aust Microbiol. 1986;7:188A.

    Google Scholar

  25. 25.

    Thorel MF. Relationship between Mycobacterium avium, M. paratuberculosis and mycobacteria associated with Crohn’s disease. Ann Rech Vet. 1989;20(4):417–29.

    CAS  PubMed  Google Scholar

  26. 26.

    Haagsma J, Mulder CJJ, Eger A, Tygat CNJ. Mycobacterium paratuberculosis isole chez des patients attients de maladie de Crohn. Resultant preliminaires. Acta Endos. 1991;21:255–60.

    Article  Google Scholar

  27. 27.

    Juste RA, Elguezabal N, Garrido JM, Pavon A, Geijo MV, Sevilla I, Cabriada JL, Tejada A, Garcia-Campos F, Casado R, et al. On the prevalence of M. avium subspecies paratuberculosis DNA in the blood of healthy individuals and patients with inflammatory bowel disease. PLoS ONE. 2008;3(7):e2537.

    Article  Google Scholar

  28. 28.

    Greenstein RJ, Su L, Fam PS, Stabel JR, Brown ST. Failure to detect M. avium subspecies paratuberculosis in Johne’s disease using a proprietary fluorescent in situ hybridization assay. BMC Res Notes. 2018;11(1):498.

    Article  Google Scholar

Download references

Acknowledgments

The Bronx Veterans Affairs Research Foundation provided the facility in which this study was performed.

Funding

The project was funded intramurally by the Bronx Veterans Research Fund Inc. C. Heffner provided an unrestricted grant which was used to purchase the Keyence microscope. Neither the Bronx Veterans Research Fund Inc., nor C. Heffner had any role in the study design, data collection and analysis, decision to publish, or preparation of the manuscript.

Author information

Affiliations

Authors

Contributions

Conceived and designed the study: RJG. STB. Obtained samples. BG, PE. Performed the laboratory component of the study: LS, PSF, PE, RJG. Reviewed the data: RJG, LS, PSF, BG, PE, STB. Wrote the manuscript. RJG. RJG, LS, PSF, BG, PE, STB. Each author agrees to be accountable for all aspects of this work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. RJG, LS, PSF, BG, PE, STB. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Robert J. Greenstein.

Ethics declarations

Ethics approval and consent to participate

This study was approved by the Research & Development Committee at the VAMC Bronx NY (0720-06-038).

Consent for publication

Tissue was non-identifiable, accordingly no consent was necessary. Research & Development Committee at the VAMC Bronx NY (0720-06-038).

Competing interests

Dr. Greenstein has three MAP related patents based on his published work in this field.

Patents Issued

US Patent # 7846,420: Issued: June 18, 2013. US Patent # 7,902,350: Issue Date March 8, 2011. US Patent # 8,507,251: Issue Date August 13, 2013.

Dr. Sheldon T. Brown has the following potential Conflict of Interest.

STB was a member of the National Academy of Sciences of the USA panel that issued the Report “Diagnosis and Control of Johne’s Disease.” ISBN 0-309-08611-6.

LS, PSF & BG report no potential conflict of interest.
